    Home elevators

    FUJISJ home lifts in steel belt, wire rope and force drive
    configurations — full technical specifications

    Max travel height

    Steel belt & force drive
    23 m

    Maximum
    travel

    Home lifts

    A lift that fits the
    house you already have.

    Home lifts come in three drive configurations, and the right one depends on your
    available shaft space, pit depth and overhead height as much as on how many
    people need to travel. We survey the space first, then specify.

    • 3 to 5 person capacity, 230–400 kg rated load.
    • Centre opening doors, 700–800 mm openings.
    • Travel heights up to 19,000–23,000 mm.
    • Speeds from 0.4 to 1.0 m/s.
    Technical specifications

    Three drive types.
    Pick by the space you have.

    Specification Steel Belt Wire Rope Force Drive
    Rated load 260–400 kg 260 kg 230–400 kg
    Capacity 3–5 persons 3 persons 4–5 persons
    Speed 0.4–1.0 m/s — 0.4–1.0 m/s
    Door type Centre opening Centre opening Centre opening
    Door opening 700 mm — 700–800 mm
    Car size (W×D) 900×850 mm — 1100–1200 × 900–1000 mm
    Hoistway (W×D) 1500×1100 mm — 1600–1700 × 1150–1450 mm
    Overhead height — 3200 mm 2200 mm
    Pit depth — 300 mm 3000–3200 mm
    Max travel height 19,000–23,000 mm — 19,000–23,000 mm

    Specifications as supplied by FUJISJ. A dash indicates a figure not stated in the manufacturer's technical sheet for that drive type — ask us and we will confirm it against your site.

    Ask us which drive type suits your building

    Passenger elevators

    For commercial and public buildings —
    apartment blocks, offices, hospitals and
    universities, sized to traffic.

    Home elevators

    Compact residential lifts for 3 to 5
    people, designed to fit the shaft space
    a house can realistically give.

    Observation elevators

    Panoramic cars for atriums and
    retail spaces, where the lift is part
    of the architecture.

    Tell us about your building

    Send us your hoistway dimensions, travel height and number of floors
    and we will tell you which drive type fits.
